As an experienced NTN – SNR supplier in the Benelux, LM Systems understands that technical specifications on paper are only the starting point. The real challenge lies in translating these values into a reliable and durable machine that operates trouble-free for years under varying conditions.
Technical challenges in linear motion
Within the manufacturing industry, machines are subjected to heavier loads while requirements for accuracy and speed continue to increase. Older types of guides regularly exhibit play or increased rolling resistance under intensive use, for example due to inadequate lubrication. This leads to reduced structural stiffness and affects the repeatability of positioning.
For an engineer, this means that the Total Cost of Ownership increases because maintenance intervals become shorter and the lifespan of components decreases. Selecting the right components therefore requires in-depth knowledge of dynamic load ratings and moment loads.
NTN – SNR linear solutions
The technology behind NTN – SNR linear solutions provides an answer to these complex challenges by utilizing advanced ball chain technology. This innovation ensures that the balls in the guide do not come into direct contact with each other but remain separated by a flexible chain.
The result is a significant reduction in noise generation and extremely consistent running performance. More importantly for the engineer, this technology creates lubrication reservoirs, allowing lubrication intervals of up to 5,000 kilometers. This reduces maintenance pressure and increases the reliability of the entire installation.
Specialized NTN – SNR supplier Benelux
Choosing a certified NTN – SNR supplier in the Benelux means choosing certainty based on one hundred years of experience in bearing technology. The products are developed and extensively tested under demanding production conditions. For us as a supplier, these tests are conducted in Bielefeld (DE). This ensures that you are provided with components that comply with strict certifications such as ISO9001 and ISO14001.
The linear modules offer unique advantages through the integration of pulleys in the AXC and AXDL series. This design results in a shorter installation length, allowing you as a designer to retain more stroke within a compact machine base. The flexibility in drive selection between timing belts or spindles within the same profile also makes it possible to implement standardization in your designs.
LM Systems as your partner and NTN – SNR supplier
As an NTN – SNR supplier, we act as an extension of your own engineering department. We possess the expertise to modify standard modules to meet your specific requirements. This includes, for example, the application of special greases for use in vacuum environments or the application of durable coatings against corrosion.
Our in-house cleanroom facilities enable us to assemble systems that meet the highest cleanliness standards. In addition, we mitigate design risks by contributing to calculations for the desired service life and stiffness of your linear system.
The versatility of linear technology is reflected across various sectors where precision and speed converge:
- In the semiconductor industry, the guides are used due to their low particle emission and high positioning accuracy.
- The packaging industry benefits from the AXS series, which can reliably move heavy loads of up to 1000 kg as a Z-axis at high cycle times.
- In medical technology, the closed profiles of the AXC modules provide protection against contamination and ensure hygienic operation.
- For laboratory automation, compact modules with integrated drive systems are the ideal solution for limited installation spaces.
Discover NTN – SNR at LM Systems
When should you choose NTN – SNR products?
Choosing NTN – SNR via LM Systems is the right step when your project requires a combination of high load capacity and minimal maintenance requirements. You choose us when you need fast response and solid technical substantiation. From a single replacement rail to a fully assembled multi-axis system, we provide the support required to successfully bring your machine into production readiness. We guarantee high stock availability and short communication lines, enabling you to respond quickly to changes in your design.
Technical advice
When realizing a high-quality linear system, you need more than just the best components. It requires a partner who combines the technical depth of NTN – SNR products with engineering support and customization capabilities. By focusing on quality and reliability, you reduce risks within your machine-building projects and create a competitive advantage.
Would you like to discuss the technical details of your specific application with a specialist, or do you need CAD downloads of our linear modules? Contact us for an in-depth introduction or request technical advice for your project directly.
